Travelstar 5K100 Hard Disk Drive Specification
35
6.6 Acoustics
6.6.1 Sound power levels
The criteria of A-weighted sound power level are described below.
Measurements are to be taken in accordance with ISO 7779. The mean of the sample of 40 drives is to be less than
the typical value. Each drive is to be less than the maximum value. The drives are to meet this requirement in both
board down orientations.
The background power levels of the acoustic test chamber for each octave band are to be recorded.
Sound power tests are to be conducted with the drive supported by spacers so that the lower surface of the drive be
located 25±3 mm above from the chamber floor. No sound absorbing material shall be used.
The acoustical characteristics of the disk drive are measured under the following conditions:
Mode definitions
• Idle mode: Power on, disks spinning, track following, unit ready to receive and respond to control line com-
mands.
• Operating mode: Continuous random cylinder selection and seek operation of the actuator with a dwell
time at each cylinder. The seek rate for the drive is calculated with the following formula:
Ns= 0.4/(Tt + T1)
where:
Ns = average seek rate in seeks/s
Tt = published seek time from one random track to another without including rotational latency
T1= equivalent time in seconds for the drive to rotate by half a revolution
6.6.2 Discrete tone penalty
Discrete tone penalties are added to the A-weighted sound power (Lw) with the following formula only when
determining compliance.
Lwt(spec) = Lw = 0.1Pt + 0.3 < 4.0 (Bels)
where
Lw = A-weighted sound power level
Pt = Value of desecrate tone penalty = dLt – 6.0(dBA)
dLt = Tone-to-noise ratio taken in accordance with ISO 7779 at each octave band
Table 24: Weighted sound power
A-weighted sound power
Typical (Bels) Maximum (Bels)
100GB, 80GB, 60GB
models
Idle 2.5 2.7
Operating 2.7 2.9
40GB, 30GB, 20GB
models
Idle 2.2 2.4
Operating 2.4 2.6
