SLIDE COMPOUND MITER SAW MODEL NO. C 10FSHC
PARTS LIST
A B CDE
372389 0HUR BALL BEARING 1
372390 0HUZ BALL BEARING 1
372391 0HVK BALL BEARING 1
326905 0HX9 NEEDLE BEARING 1
372393 0J6H FLAT WASHER φ15.02*19.2-11
317578 0JEA C-RING 1
726512 0JEC C-RING 1
372396 0JG7 PARALLEL KEY 1
372397 0K6X CR. RE. TRUSS HD. SCREW M4*0.7-65
372398 0KBP
CR. RE. PAN HD. TAPPING SCREW M4*18-81
372399 0KCP CR. RE. PAN HD. TAPPING &
WASHER SCREW
M5*12-60 2
326910 0QM2 BRUSH HOLDER ASS'Y Φ27*26.5 2
372085 0QQT CARBON BRUSH 2
372402 0QR0 BRUSH CAP 2
372403 20ZA C-RING 1
372404 2NA3 CR. RE. TRUSS HD. SCREW M5*.8-10 3
372405 2RUY BALL BEARING 1
372406 33NE MAGNET 1
372407 35V0 BEARING BUSHING 1
372408 3FJ6 CUTTER SHAFT 1
372409 3FJ7 COLLAR 1
372410 3FJ8 HELIX GEAR 1
372411 3FJA GEAR SHAFT 1
372412 3FJD FRONT HOUSINT 1
372413 3FJE SPINDLE LOCK 1
372414 3FJF LOCK KNOB 1
372415 3FJR GEAR BOX 1
372416 3GGC COMPRESSION SPRING 1
372417 3GGU OIL CAP 1
372418 3GGW FLOW GUIDE 1
372419 3GH6 HALL SENSOR ASS'Y 1
372420 3H48 ARMATURE ASS'Y 1
372421 3H49 CONTROLLER ASS'Y 1
372422 3H5A NEEDLE ROLLER 2
372423 3H5C OIL PAPER 1
372424 3H7F FIELD ASS'Y 1
372425 3H9V LEAD WIRE ASS'Y 1
372426 3HHY
CR. RE. PAN HD. TAPPING SCREW M5*16-25 2
372427 3HJ2 CR. RE. PAN HD. SCREW &
WASHER
M5*0.8-60 4
372428 3HJN HEX. SOC. HD. CAP SCREWS M5*0.8-25 4
372429 3HJS HEX. SOC. TRUSS HD. SCREW M4*0.7-61
372430 3HK5 FLAT WASHER φ5*16-21
372431 3HLH HEX. SOC. SET SCREW M5*0.8-62
372432 3HYZ HEX. SOC. HD. CAP BOLT M5*0.8-10 1
372433 3JDW PARALLEL KEY 1
372434 3M3Z CENTER SHAFT WASHER 1
372435 3M40 BUMPER 1
372436 3M4W STRAIGHT BEVEL GEAR 1
372437 3TU5 GEAR CASE 1
372438 3TUB MOTOR REAR COVER 1
372439 3U3A MOTOR COVER 1
