Oil supply points:
* Rotary portion of hinge
* Rotary portion of vise assembly
* Rotary portion of holder (A)
8. Cleaning
Periodically remove chips, dust and other waste material from the surface of the power
tool, especially from the inside of the lower guard with a damp, soapy cloth. To avoid a
malfunction of the motor, protect it from contact with oil or water.
If the laser line becomes invisible due to chips and the like adhered onto the window of the
laser marker’s light-emitting section, wipe and clean the window with a dry cloth or a soft
cloth moistened with soapy water, etc.
9. Service parts list
A: HKU#
B: I.D. No.
C: Description
D: Size
E: Qʼty
CAUTION: Repair, modifi cation and inspection of Hitachi Power Tools must be
carried out by a Hitachi Authorized Service Center.
This Parts List will be helpful if presented with the tool to the
Hitachi Authorized Service Center when requesting repair or other
maintenance. In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each country must be
observed.
MODIFICATIONS:
Hitachi Power Tools are constantly being improved and modifi ed to incorporate the latest
technological advancements.
Accordingly, some parts (i.e. code numbers and/or design) may be changed without prior notice.
SERVICE AND REPAIRS
All quality power tools will eventually require servicing or replacement of parts because of wear
from normal use. To assure that only authorized replacement parts will be used and that the
double insulation system will be protected, all service (other than routine maintenance) must be
performed by an AUTHORIZED HITACHI POWER TOOL REPAIR CENTER ONLY.
NOTE: Specifi cations are subject to change without any obligation on the part of
HITACHI.
