--- 16 ---
In the case of left bevel angle cutting, remove sub fence (C)
by sliding to the side and removing from the top as shown in
Fig. 21. Loosen knob (B) then remove sub fence (C) (Fig. 22).
Sub fence (C)
Fig. 22
WARNING: To attach sub fence (C), insert then securely
tighten knob (B). If knob (B) is loose, sub
fence (C) may move during cutting and result in
injury.
Fence (B)
Knob (B)
