English
19
SPECIFICATIONS
Max. Cutting
Capacity
Height × Width
65 mm × 312 mm
**75 mm × 262 mm with aux. board (30 mm)
Miter 45°
65 mm × 220 mm
**75 mm × 185 mm with aux. board (20 mm)
Bevel
Left 45°
45 mm × 312 mm
**50 mm × 252 mm with aux. board (30 mm)
Right 5°
60 mm × 312 mm
**70 mm × 252 mm with aux. board (30 mm)
Compound
Bevel (Left) 45° + Miter 45°
45 mm × 220 mm
**50 mm × 170 mm with aux. board (30 mm)
Bevel (Right) 5° + Miter 45°
60 mm × 220 mm
**70 mm × 170 mm with aux. board (30 mm)
Saw Blade Dimensions (oD × iD × Thickness) 216 mm × 30 mm × 2 mm
Miter Cutting Angle Right 0° – 57°, Left 0° – 45°
Bevel Cutting Angle Right 0° – 5°, Left 0° – 48°
Compound Cutting Angle
Bevel (Left) 0° – 45°
Miter (Right and Left) 0° – 45°
Bevel (Right) 0° – 5°
Voltage (by areas)*
(110 V, 230 V)
Power Input* 1050 W
No-Load Speed
C8FSHE • C8FSE: 5500 min
–1
C8FSHE(S) • C8FSE(S): 4100 min
–1
: with Soft Start
Machine Dimensions (Width × Depth × Height) 555 mm × 790 mm × 485 mm
Weight (Net)
14.5 kg (C8FSHE • C8FSHE(S)) /
14 kg (C8FSE • C8FSE(S))
Laser Marker
(Only Model C8FSHE / C8FSHE(S))
Maximum output
Po<3 mW Class
Laser Product
(Iambda) 654 nm
Laser medium Laser Diode
* Be sure to check the nameplate on product as it is subject to change by areas.
When cutting the workpiece which has the dimension of “**” there might be some possibility of the lower end of the circular
saw to touch with the workpiece, even if the motor head is located at the lower limit position. Pay attention when cutting the
workpiece. For further details, refer to “PRACTICAL APPLICATIONS”. Mount the auxiliary board on the fence surface (Refer
( ) the thickness of auxiliary board). Refer to “10. Cutting large workpieces” (Fig. 20, 21).
1. Minimum size of the workpiece.
All workpieces that can be clamped left or right from the saw blade with the supplied vise assembly.
Model C8FSHE • C8FSHE(S) • C8FSE • C8FSE(S): 245 × 90mm (length × width)
2. Maximum cutting depth.
Model C8FSHE • C8FSHE(S) • C8FSE • C8FSE(S): 65mm (Miter 0° × Bevel 0°)
PRIOR TO OPERATION
CAUTION
Make all necessary adjustments before inserting the
plug in the power source.
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements speci ed on the product
nameplate.
Do not use with direct current, or transformers such as
boosters. Doing so may result in damage or accidents.
2. Power switch
Ensure that the power switch is in the OFF position. If the
plug is connected to a receptacle while the trigger switch
is in the ON position, the power tool will start operating
immediately, inviting serious accident.
3. Extention cord
When the work area is removed from the power source,
use an extension cord of su cient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
STANDARD ACCESSORIES
216 mm TCT Saw blade (mounted on tool) ...................1
Dust bag .......................................................................1
10 mm Box wrench .......................................................1
Vise Assembly ..............................................................1
Holder ...........................................................................1
Side Handle ..................................................................1
Sub Fence (mounted on tool) ........................................1
Standard accessories are subject to change without notice.
APPLICATION
Cutting various types of aluminium sash and wood.
