Hitachi CP-AX3005 User Guide

RS-232C Communication / Network command table (continued)
22
(continued on next page)
Names Operation Type Header
Command Data
CRC Action Type Setting code
ASPECT
Set
 %(() 03 06 00 9E D0 01 00 08 20 00 00
 %(() 03 06 00 0E D1 01 00 08 20 01 00
NATIVE %(() 03 06 00 5E D7 01 00 08 20 08 00
 %(() 03 06 00 CE D6 01 00 08 20 09 00
 %(() 03 06 00 3E D6 01 00 08 20 0A 00
1250$/ %(() 03 06 00 5E DD 01 00 08 20 10 00
Get %(() 03 06 00 AD D0 02 00 08 20 00 00
OVER SCAN
Get %(() 03 06 00 91 70 02 00 09 22 00 00
Increment %(() 03 06 00 F7 70 04 00 09 22 00 00
Decrement %(() 03 06 00 26 71 05 00 09 22 00 00
OVER SCAN
Reset
Execute %(() 03 06 00 EC D9 06 00 27 70 00 00
V POSITION
Get %(() 03 06 00 0D 83 02 00 00 21 00 00
Increment %(() 03 06 00 % 04 00 00 21 00 00
Decrement %(() 03 06 00 %$ 05 00 00 21 00 00
V POSITION
Reset
Execute %(() 03 06 00 E0 D2 06 00 02 70 00 00
H POSITION
Get %(() 03 06 00 F1 82 02 00 01 21 00 00
Increment %(() 03 06 00 97 82 04 00 01 21 00 00
Decrement %(() 03 06 00 46 83 05 00 01 21 00 00
H POSITION
Reset
Execute %(() 03 06 00 1C D3 06 00 03 70 00 00
H PHASE
Get %(() 03 06 00 49 83 02 00 03 21 00 00
Increment %(() 03 06 00 2F 83 04 00 03 21 00 00
Decrement %(() 03 06 00 FE 82 05 00 03 21 00 00
H SIZE
Get %(() 03 06 00 % 02 00 02 21 00 00
Increment %(() 03 06 00 D3 82 04 00 02 21 00 00
Decrement %(() 03 06 00 02 83 05 00 02 21 00 00
H SIZE Reset
Execute %(() 03 06 00 68 D2 06 00 04 70 00 00
AUTO ADJUST
EXECUTE
Execute %(() 03 06 00 91 D0 06 00 0A 20 00 00
PROGRESSIVE
Set
OFF %(() 03 06 00 4A 72 01 00 07 22 00 00
TV %(() 03 06 00 DA 73 01 00 07 22 01 00
),/0 %(() 03 06 00 2A 73 01 00 07 22 02 00
Get %(() 03 06 00 79 72 02 00 07 22 00 00
VIDEO NR
Set
/2: %(() 03 06 00 26 72 01 00 06 22 01 00
MID %(() 03 06 00 D6 72 01 00 06 22 02 00
HIGH %(() 03 06 00 46 73 01 00 06 22 03 00
Get %(() 03 06 00 85 73 02 00 06 22 00 00
&2/2563$&(
Set
AUTO %(() 03 06 00 0E 72 01 00 04 22 00 00
5*% %(() 03 06 00 9E 73 01 00 04 22 01 00
SMPTE240 %(() 03 06 00 6E 73 01 00 04 22 02 00
REC709 %(() 03 06 00 FE 72 01 00 04 22 03 00
REC601 %(() 03 06 00 CE 70 01 00 04 22 04 00
Get %(() 03 06 00 3D 72 02 00 04 22 00 00
