44
5. Remove the protection film. Loosen the
screw that secures the lamp. Refer to the
right figure to identify the screw.
6. Disconnect the lamp's wire connector from
7. the projector, and then slowly pick up the
lamp by the handle.
CAUTION
• Pulling it too quickly may cause the lamp to
break and scatter broken glass in the projector.
• Do not place the lamp in locations where water
might splash on it, children can reach it, or
near flammable materials.
• Do not insert your hands into the projector
after the lamp is removed. If you touch the
optical components inside, it could cause color
unevenness and distortion of the projected
images.
8. Insert the new lamp into the lamp
compartment and make sure it fits in the
projector. Connect the new lamp’s wire
connector to the projector.
9. Tighten the screw that secures the lamp.
CAUTION
• Loose screw may cause a bad connection,
which could result in malfunction.
• Do not over tighten the screw.
10. Ensure the handle is fully laid flat and
locked in place.
11. Replace the new protection film that comes
with the new lamp.
1
2
3
2 1
To Next Page
