-3-
Model CS 33EA CS 33ET Remarks
Engine type Air-cooled, two-cycle gasoline engine
Cylinder quantity
ʊ inner diameter x stroke
1-37 x 30 mm
Engine displacement 32.3 mL
Momentary no-load
revolutions
12,000 min
-1
Service revolutions 7,000 to 9,000 min
-1
Revolutions at actual
work
Idling revolutions 2,800 to 3,200 min
-1
Rotation direction Clockwise
When viewed from end
of the output shaft
Service fuel
Mixed gasoline
Gasoline: oil for two-cycle exclusive = (25 to 50):
1
Fuel tank capacity 30 mL (Continuously for 20 to 30 minutes)
Carburetor Diaphragm type (from Walbro)
Spark plug NGK BPM6A or BPMR6A
Starting method Coil damper type recoil starter method
Air cleaning method Dry
Stopping method Ground
Muffler type Silencer
Power transmission
method
Automatic centrifugal clutch
Guide bar length 350 mm (14 inch), SN 300 mm (12 inch), SN SN: Sprocket nose
Saw chain used 91VG-52 91VG-45 From Oregon
Saw chain Pitch: 3/8 inch; gauge: 0.05 inch
Sprocket Star, six teeth
Chain oil feeding method Automatic feed
Oil amount adjusting
type
Chain oil tank capacity 190 mL
Chain oil discharge rate 3 to 8 mL/minute (8,000 min
-1
)
Standard opening
degree: 1-1/4 turns
back from totally
closed position
Chain oil used Dedicated chain oil
Handle Equipped with anti-vibration device
Anti-vibration mechanism Engine floating type
Dry weight 4.3 kg 4.1 kg
Overall dimensions
(L x W x H)
394 x 262 x 238 mm 279 x 264 x 225 mm
Excluding chain and
chain bar
SPECIFICATIONS
