PART
CS 33EB
DESCRIPTION REMARKS
1 668-5416 CHAIN BAR CLAMP NUT 2
2 NAME PLATE 1
3 668-5406 SIDE COVER SUB 1
4 668-5387 BRAKE SUPPORT 1
5 668-5388 BRAKE LINK 1
6 668-5392 BRAKE LINK COVER 1
7 305-812
TAPPING SCREW (W/FLANGE) D4 X 16 (BLACK) 7
8 668-5389 BRAKE SPRING 1
9 668-5362 CLUTCH 1
10 668-5403 CLUTCH HOUSING 1
11 668-5361 NEEDLE BEARING (D) 1
12 668-5414 CLUTCH WASHER 1
13 668-5360 CRANK SHAFT COLLAR 1
14 668-5390 BRAKE BAND 1
15 668-5415 TAPPING SCREW D3 X 8 2
16 668-5393 CHAIN PULLER 1
17 668-5394 GUIDE PLATE 1
* 18 668-5170 SAW CHAIN (3/8 X 12") 91VG-45E 1
* 18 668-5171 SAW CHAIN (3/8 X 14") 91VG-52E 1
* 18 669-6330 SAW CHAIN (3/8 X 16") 91VG-57E 1
* 19 668-5258 BAR 12 INCH 1
* 19 668-5260 BAR 14 INCH 1
* 19 668-5262 BAR 16 INCH 1
* 20 668-5405 CYLINDER (B) 1
* 20 668-5404 CYLINDER (A) 1
FOR EUROPE, USA, CAN (SINCE 8. 2009 FOR FRG)
* 21 668-5086 SPARK PLUG BPMR6A 1
* 21 668-5085 SPARK PLUG BPM6A 1 EXCEPT FOR EUROPE, RUS,
AUS, CHN, SAF, MEX, PAN, VIE
* 22 668-5317 COVER PACKING (B) 1
FOR EUROPE, USA, CAN (SINCE 8. 2009 FOR FRG)
* 23 668-5315 SCAVENGING COVER (B) 1 FOR EUROPE, USA, CAN (SINCE 8. 2009 FOR FRG)
* 24 669-6315 SEAL LOCK HEX. SOCKET HD. BOLT M4 X 8 6 FOR EUROPE, USA, CAN (SINCE 8. 2009 FOR FRG)
25 668-5318 INTAKE PACKING 1
26 668-5319 INTAKE 1
27 949-812 HEX. SOCKET HD. BOLT M4 X 10 (10 PCS.) 2
28 668-5322 CARBURETOR INSULATOR 1
29 669-6316 O-RING 1
30 668-5321 PULSE GUIDE 1
* 31 668-5435 CARBURETOR ASS'Y (B) 1 INCLUD. 36-51
* 31 668-5436 CARBURETOR ASS'Y (A) 1
INCLUD. 36-51 FOR EUROPE USA, CAN
(SINCE 8. 2009 FOR FRG)
32 668-5323 CLEANER SUPPORT 1
33 302-089
TAPPING SCREW (W/FLANGE) D5 X 20 (BLACK) 12
34 668-5408 WASHER 5 9
35 669-6317 HEX. SOCKET HD. BOLT M5 X 45 2
36 669-6318 IDLE ADJUSTING SCREW 1
37 669-6319 PASSAGE GASKET 1
38 669-6320 PASSAGE PLATE 1
39 669-6321 PUMP GASKET 1
40 669-6322 PUMP BODY 1
41 668-5218 HINGE PIN SET SCREW 1
9 - 09 - 3 -
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
To Next Page
