MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before use.
It is important that you read, fully understand and
observe the following safety precautions and warnings.
Careless or improper use of the unit may cause serious
or fatal injury.
Off /Stop
Read, understand and follow all warnings and
instructions in this manual and on the unit.
Emergency stop
Always wear eye, head and ear protectors when using
this unit.
Fuel and oil mixture
Warning, kickback danger. Be careful of possible
sudden and accidental upward and/or backward motion
of the guide bar.
Chain oil fi ll
One-handed usage not permitted. While cutting, hold
saw fi rmly with both hands with thumb fi rmly locked
around front handle.
Carburetor adjustment - Idle speed
Chain brake Carburetor adjustment - Low speed mixture
Choke - Run position (Open) Carburetor adjustment - High speed mixture
Choke - Choked position (Closed) Hot surface
On/Start
Contents
WHAT IS WHAT? .............................................................................. 3
WARNINGS AND SAFETY INSTRUCTIONS .................................... 3
SPECIFICATIONS ............................................................................. 5
ASSEMBLY PROCEDURES ............................................................. 6
OPERATING PROCEDURES ............................................................ 7
MAINTENANCE .............................................................................. 11
Parts breakdown
