Hitachi CS 40EA Technical Data And Service Manual

-2-
1. Specifications
Model
Item
CS 40EA (S) CS 40EA (PS) Remarks
Type of engine Two-cycle, air-cooled gasoline engine -
Bore size x stroke 41.0 mm dia. x 30 mm -
Engine displacement 39.6 mL -
Max. engine speed 13,000 min
-1
-
Service revolutions 7,000 to 9,000 min
-1
Revolutions at
actual work
Idle engine speed 2,900 to 3,300 min
-1
-
Rotating direction Clockwise
When viewed from end
of the output shaft
Fuel
Mixed fuel of gasoline and two-cycle oil
at 25 to 50:1
-
Fuel tank capacity 0.38 L (for 20 to 30 min. of continuous operation) -
Carburetor Diaphragm type (with Priming pump) Walbro
Ignition plug NGK BPMR7A -
Starting Recoil starter type (with S-start) -
Air cleaner Dry type -
Stopping Ground -
Muffler Silencer -
Clutch Automatic centrifugal -
Guide bar length
330 mm (13”), 380 mm (15”),
400 mm (16”), 450 mm (18”)
-
Type of saw chain 95VP-56 , 95VP-64 , 95VP-66 , 95VP-72 OREGON
Saw chain Pitch: 0.325” , Gauge: 1.27 mm (0.05”) -
Sprocket Star, seven teeth -
Chain oil feeding method Automatic feed -
Chain oil fuel tank
capacity
0.24 L -
Chain oil discharge rate ~ 8 mL/min (10,000 min
-1
)-
Chain oil Dedicated chain oil -
Handle Equipped with anti-vibration device
Structure to hang with
three coil-springs
Anti-vibration mechanism Engine floating type -
Dry weight 4.4 kg 4.4 kg
Dimensions (L x W x H) 381 x 229 x 283 mm
Without saw chain and
guide bar
Sound pressure level LpA 103 dB (A) compliant with ISO 22868
Sound power level Lw measured 113 dB (A) compliant with ISO 22868
Sound power level LwA 114 dB (A) compliant with 2000/14/EC
Front handle 2.2 m/s
2
Vibration
level
Rear handle 3.2 m/s
2
compliant with ISO 22868
