SPECIFICATIONS
○ Code “CS” of model name means “Chain saw”
Model CS40EA (45PS)
Type of equipment Chain saw, portable
Engine Size (cu. in.) 2.41 (39.6 ml)
Spark Plug NGK BPM-7A or BPMR-7A or equivalent
Fuel Tank Capacity (US pint) 0.80 (380 ml)
Chain Oil Tank Capacity (US pint) 0.51 (240 ml)
Dry Weight (lbs)
(Without guide bar and chain)
9.9 (4.5 kg)
Guide bar length (in.) 18 (450 mm)
Chain pitch (in.) 0.325 (8.26 mm)
Chain gauge (in.) 0.05 (1.27 mm)
Sound pressure level
LpA (dB (A))
by ISO 22868
103
Sound power level
Lw measured (dB (A))
by ISO 22868
Sound power level LwA (dB (A))
by 2000/14/EC
113
114
Vibration level (m/s
2
)
by ISO 22867
Front handle
Rear handle
2.2
3.2
Max. engine power
by ISO 7293 (kW)
1.8/10500
Max. engine speed (min
-1
) 13000
Idle engine speed (min
-1
) 3000
Specifi c fuel consumption (g/kWh) 480
Type of chain
95VP
(Oregon)
Max. chain speed (m/sec) 23.1
Sprocket (number of teeth) 7
NOTE: Equivalent noise level/vibration levels are calculated as the time-weighted energy total for noise/vibration levels under various working
conditions with the following time distribution: 1/3 idle, 1/3 full, 1/3 racing speed.
* All data subject to change without notice.
Declared single-number noise emission values are the sum of measure values and the associated uncertainty of 3dB and they represent
upper boundaries of the range of values which is likely to occur in measurements.
