Hitachi D13VF Parts List

*
ALTERNATIVE PARTS --- 3 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
D 13VF
8 -- 01
1 311-959 SPECIAL SCREW (LEFT HAND) M6X23 1
2 319-527 CHUCK WRENCH 13VLR-J 1
3 950-288 VINYL BAND 1
* 4 319-303 DRILL CHUCK 13VLR-J 1 INCLUD.2
* 4 319-304
DRILL CHUCK 13VLRD-N (W/O CHUCK WRENCH) 1
5 319-346 SPINDLE (A) 1
6 948-001 RETAINING RING FOR D32 HOLE 1
7 600-2VV BALL BEARING 6002VVCMPS2L 1
8 939-544 RETAINING RING FOR D15 SHAFT (10 PCS.) 1
9 305-701 TAPPING SCREW (W/FLANGE) D5X60 2
10 319-345 GEAR COVER (A) 1
11 627-VVM BALL BEARING 627VVC2PS2L 1
12 319-299 FINAL GEAR 1
13 319-547 SECOND PINION (B) 1
14 319-544 FIRST GEAR 1
15 606-ZZM BALL BEARING 606ZZC2PS2L 1
16 316-458 TAPPING SCREW D5X40 (BLACK) 1
17 319-344 INNER COVER 1
18 608-DDM BALL BEARING 608DDC2PS2L 1
* 19 360-543U ARMATURE ASS’Y 110V-120V 1 INCLUD.18,23,24
* 19 360-543E ARMATURE 220V-230V 1
* 19 360-543F ARMATURE 240V 1
20 319-329 FAN GUIDE 1
21 981-421 HEX. HD. TAPPING SCREW D4X55 2
* 22 340-494C STATOR 120V 1
* 22 340-486D STATOR 110V 1
* 22 340-504E STATOR 230V-240V 1
23 982-631 WASHER (A) 1
24 608-VVM BALL BEARING 608VVC2PS2L 1
25 319-328 HOUSING 1
26 NAME PLATE 1
27 319-331 HANDLE (B) 1
28 303-694 TAPPING SCREW (W/FLANGE) D4X35 2
29 301-653
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 1
30 319-332 GRIP COVER 1
31 319-337 SCREW (PLASTIC TIE) D4X25 2
32 HITACHI LABEL 1
33 319-330 HANDLE (A) 1
34 955-203 BRUSH HOLDER 2
* 35 319-341 INTERNAL WIRE (BLUE) 86L 1 FOR USA,CAN
* 35 320-204 CHOKE COIL (BLUE) 110V 1 FOR GBR (110V)
* 35 320-197 CHOKE COIL (BLUE) 220V-240V 1 FOR AUS,NZL,EUROPE
36 999-041 CARBON BRUSH (1 PAIR) 2
* 37 319-340 INTERNAL WIRE (BROWN) 86L 1 FOR USA,CAN
* 37 320-203 CHOKE COIL (BROWN) 110V 1 FOR GBR (110V)
* 37 320-196 CHOKE COIL (BROWN) 220V-240V 1 FOR AUS,NZL,EUROPE
38 316-166 PUSHING BUTTON 1
* 39 319-302 SWITCH (1P SCREW TYPE) W/LOCK 1 FOR USA,CAN
* 39 319-339 SWITCH (1P SCREW TYPE) W/LOCK 1 FOR GBR (110V)
* 39 320-195 SWITCH (1P SCREW TYPE) W/LOCK 1 FOR AUS,NZL,EUROPE
40 984-750 TAPPING SCREW (W/FLANGE) D4X16 2
