Hitachi DB 3DL User Manual

*
ALTERNATIVE PARTS--- 2 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
9 -- 06
DB 3DL
1 326-348 GEAR BOX ASS’Y 1 INCLUD. 2-28, 30
2 315-984 RETAINING RING 1
3 315-983 WASHER (D) 1
4 320-409 GUIDE SPRING 1
5 319-921 GUIDE SLEEVE (A) 1
6 326-342 CLUTCH DIAL 1
7 326-341 NUT 1
8 326-340 SPRING 1
9 326-339 WASHER (D) 1
10 319-535 STEEL BALL D3.5 (10 PCS.) 1
11 326-349 GEAR CASE 1
12 326-345 SHIFT ARM 1
13 326-338 PIN SET (3 PCS.) 3
14 317-788 STEEL BALL D3 3
15 326-323 LOCK RING 1
16 326-324 NEEDLE ROLLER SET (6 PCS.) 6
17 326-329 NEEDLE 2
18 326-325 CARRIER 1
19 326-327 PLANET GEAR (C) SET (3 PCS.) 3
20 326-326 RING GEAR 1
21 326-328 WASHER (B) 1
22 326-330 PINION (C) 1
23 326-332 PLANET GEAR (B) SET (3 PCS.) 3
24 326-331 SLIDE RING GEAR 1
25 326-333 PINION (B) 1
26 326-335 PLANET GEAR (A) SET (3 PCS.) 3
27 326-334 FIRST RING GEAR 1
28 326-336 WASHER (A) 1
29 326-319
MACHINE SCREW (W/SP. WASHER) M2.6X8 2
30 326-337 MOTOR SPACER 1
31 326-310 MOTOR 1
32 326-307 HOUSING (A).(B) SET 1
33 984-319 PAN HD. TAPPING SCREW D3X8 4
34 NAME PLATE 1
35 326-315 CLICK PLATE 2
36 317-788 STEEL BALL D3 4
37 302-086
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 1
38 HITACHI LABEL 1
39 326-308 SHIFT KNOB 1
40 326-311 SWITCH (W/LOCK) 1
41 326-313 PRINTED CIRCUIT BOARD 1
42 326-309 CLICK SPRING 1
43 326-314 HANDLE COVER 1
44 326-312 TERMINAL 2
45 326-317 BUTTON 1
46 326-316 TERMINAL SUPPORT 1
*47 326-299 BATTERY EBM 315 (EUROPE, AUS, NZL) 2
*47 326-263 BATTERY EBM 315 (USA, CAN) 2
48 326-318 CLIP 2
49 326-347 HANDLE (A).(B) SET 1 INCLUD. 36
50 320-085 GUIDE SLEEVE SET 1 INCLUD. 2-5, 10
