Hitachi DB10DL - Specifications

English
10
2. Battery Charger (UC10SFL)
Fig. 2
Nameplate
Caution plate
Body
Battery installation hole
Pilot lamp
SPECIFICATIONS
1. Cordless Driver Drill (DB10DL)
2. Battery Charger (UC10SFL)
Motor DC motor
No-load speed 0 – 400 / min
Drilling Wood (Thickness
23/32" (18 mm)
Capacity
11/16" (18 mm))
Screw Wood screw #14 × 1-1/2" (6 mm × 38 mm)
Driver Small screw 1/4" (6 mm)
Bit shank size 1/4" (6.35 mm) Hex.
Model BCL1015
Type Lithium - ion battery
Battery
Voltage DC 10.8 V
Charging & discharging
About 1,000 times
frequency
Weight 1.8 lbs. (0.8 kg)
Input power source Single phase: AC 120 V 60 Hz
Charging time
Approx. 40 min.
(At a temperature of 68°F (20°C))
Charging voltage DC 10.8 V
Charging current DC 2.0 A
Weight 0.8 lbs. (0.35 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
