Hitachi DH26PC User Manual

5
1
钻头
Drill bit
2
SDS-plus 长柄部
Part of SDS-plus shank
3
前帽
Front cap
4
夹卡
Grip
5
防尘杯
Dust cap
6
集尘器（B）
Dust collector (B)
7
按钮
Push button
8
选择杆
Change lever
9
按钮
Push button
0
钻头夹盘
Drill chuck
!
夹盘附加器
Chuck adapter
@
夹盘附加器（D）
Chuck adapter (D)
#
头
Bit
$
夹紧器
Socket
%
侧柄
Side handle
^
深度计
Depth gauge
&
安装孔
Mounting hole
*
锥柄附加器
Taper shank adapter
(
制销
Cotter
)
台座
Rest
q
取心钻具
Core bit
w
取心钻柄
Core bit shank
e
螺纹
Thread
r
中间销
Center pin
t
导板
Guide plate
y
取心钻具尖端
Core bit tip
标志
警告
以下显示的是本机器中使用的标志，请确保您在使用
前理解它们的含义。
Symbols
WARNING
The following show symbols used for the machine. Be
sure that you understand their meaning before use.
为降低伤害风险，用户必须阅读使用说明书
To reduce the risk of injury, user must read instruction
manual.
000BookDH24PHChS.indb5000BookDH24PHChS.indb5 2013/05/158:39:082013/05/158:39:08

Hitachi DH26PC Specifications

General

Input power	830 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Impact rate	4300 bpm
Rated speed (max)	1100 RPM
Impact energy (max)	3.2 J
Drilling diameter in wood (max)	32 mm
Drilling diameter in steel (max)	13 mm
Drilling diameter in concrete (max)	26 mm
Chuck type	SDS Plus
Product color	Black, Green
Adjustable speed	Yes

Weight and Dimensions

Depth	367 mm
Width	75 mm
Height	198 mm
Weight	2800 g
