After reassembly, install the battery and then check component operations as follows:
(1) Checking the direction of rotation
Press the (R) side of Pushing Button (A) [32], and check that Drill Chuck 10MM [2] rotates in the
clockwise direction (when viewed from the rear of the main body).
(In case of reverse rotation, the soldered connections of the internal wires of Motor DC12V [28] and
DC-Speed Control Switch [35] are inverse.)
(2) Checking LED operation
Turn the trigger of DC-Speed Control Switch [35] on and off, and check that the LED goes on and off.
(The LED goes on when the trigger is turned on; the LED goes off when the trigger is turned off.)
(3) Checking shift knob operation
Set Shift Knob [33] to "HIGH" (high-speed rotation) and "LOW" (low-speed rotation), and check that
rotation speed is switched correctly without any abnormal noise being generated by the gears or other
parts.
x Special Screw (Left Hand) (B) M5 X 25 [1] -------------------------------2.9 to 3.9N
•m{30 to 40kgf•cm}
x Drill Chuck 10MM [2]----------------------------------------------------------- 12.7 to 16.7N
•m{130 to 170kgf•cm}
x Tapping Screw (W/Flange) D3 X 16 (Black) [38] ------------------------ 0.8 to 1.2N
•m{8 to 12kgf•cm}
x Machine Screw M3 X 8 [26] -------------------------------------------------- 0.63 to 0.93N
•m{6.5 to 9.5kgf•cm}
x Screw Set D2 X 3.5 [17]------------------------------------------------------- 0.3 to 0.5N
•m{3 to 5kgf•cm}
2.
Precautions on Disassembly and Reassembly of Battery Charger
For precaution on the disassembly and reassembly of the charger (Model UC 10SFL), and other charger-
related precautions, refer to the Service Manual for the Model UC 10SFL.
Screw tightening torques
Checks after reassembl
