Hitachi DV 14DCL2 User Manual

4
English
1
14.4 V Rechargeable battery
(For DV14DCL2)
2
18 V Rechargeable battery
(For DV18DCL2)
3
Latch
4
Pull out
5
Insert
6
Handle
7
Push
8
Insert
9
Pilot lamp
0
Hole for connecting the
rechargeable battery
!
Drill mark
@
Hammer marks
#
Clutch dial
$
Triangle mark
%
Weak
^
Strong
&
Line
*
Shift knob
(
Low speed
)
High speed
q
Ring
w
Sleeve
e
Tighten
r
Loosen
t
Trigger switch
y
Selector button
u
and marks
Symbols
WARNING
The following show symbols
used for the machine. Be
sure that you understand
their meaning before use.
Read all safety warnings
and all instructions.
Failure to follow the warnings
and instructions may result
in electric shock, fi re and/or
serious injury.
Only for EU countries
Do not dispose of electric
tools together with
household waste material!
In observance of European
Directive 2002/96/EC
on waste electrical and
electronic equipment
and its implementation in
accordance with national
law, electric tools that have
reached the end of their life
must be collected separately
and returned to
an
environmentally compatible
recycling facility.
000BookDV14DCL2.indb4000BookDV14DCL2.indb4 2012/02/298:46:542012/02/298:46:54

Hitachi DV 14DCL2 Specifications

General

Brand	Hitachi
Model	DV 14DCL2
Category	Drill
Language	English
