Hitachi DV18DVC - 18 Volt Cordless Hammer Drill Parts List

*
ALTERNATIVE PARTS--- 2 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
3 -- 07
DV 18DVC
1 995-344 FLAT HD. SCREW (A) (LEFT HAND) M6X25 1
2 322-625
DRILL CHUCK 13VLRJ-N (W/O CHUCK WRENCH) 1
3 327-131 GEAR BOX ASS’Y 1 INCLUD. 4-33
4 327-149 CLUTCH DIAL 1
5 327-146 CLICK SPRING 1
6 327-142 O-RING 1
7 327-137 SPINDLE 1
8 327-136 SPRING (C) 1
9 327-134 RATCHET (B) 1
10 327-147 WASHER (A) 1
11 327-145 NUT 1
12 327-144 WASHER 1
13 327-135 SLIP BLOCK 2
14 327-133 STOPPER SPRING 2
15 327-132 FRONT CASE 1
16 327-143 SPRING (A) 4
17 306-936 STEEL BALL D5 4
18 327-138 WASHER (A) 2
19 327-148 SPRING (D) 1
20 328-055 RING GEAR 1
21 327-139 CARRIER 1
22 312-705 PLANET GEAR (C) SET (3 PCS.) 3
23 312-704 WASHER (A) 1
24 327-140 REAR CASE 1
25 324-357 SCREW SET D3X12 (4 PCS.) 4
26 319-753 SHIFT ARM 1
27 327-141 SLIDE RING GEAR 1
28 312-702 PINION (C) 1
29 312-699 PLANET GEAR (A) SET (6 PCS.) 6
30 312-701 PINION (B) 1
31 315-136 FIRST RING GEAR 1
32 312-716 WASHER (B) 1
33 316-955 MOTOR SPACER 1
34 327-153 MOTOR 1
35 NAME PLATE 1
36 313-687
TAPPING SCREW (W/FLANGE) D3X16 (BLACK) 8
37 317-333 MACHINE SCREW (W/SP. WASHER) M4X6 2
38 323-229 FERRITE CORE 1
39 HITACHI LABEL 1
40 327-152 HOUSING (A).(B) SET 1
41 328-057 INTERNAL WIRE (BLACK) 150L 1
42 328-056 INTERNAL WIRE (RED) 150L 1
43 327-151 PUSHING BUTTON 1
44 327-150 SHIFT KNOB 1
45 327-154 DC-SPEED CONTROL SWITCH 1
46 306-952 STRAP (BLACK) 1
47 958-715 TAPPING SCREW D4X10 2
48 996-118 HOLDER SPRING 2
49 327-155 TERMINAL 2
50 320-997 TERMINAL PIECE 1
51 322-882
BATTERY EB 1814SL (EUROPE, AUS, NZL) 2
