Hitachi E100 - Page Specifications

10
English
Model E100 (3P)
Type Brush, Self-exciting, 2-poles
Phase Single Three
AC Voltage 50 Hz 230 V 400 V
Max. Output 50 Hz 2.8 kw 8.0 kw
Rated Output 50 Hz 2.6 kw 6.4 kw
Rated Current 11.5 A
Voltage Regulator C. T. Type
Power Factor 1.0 0.8
Safety Device N. F. B
Model Robin EH63D
Type Air-cooled, 4 cycle, OHV, Gasoline Engine
Displacement 653 cm
3
Max. Output 18.2 HP (13.4 kw)
Fuel Regular Automobile Gasoline
Fuel Tank Capacity 38.2 L
Rated Continuous Operation
50 Hz Approx. 10.8 h
per a tankful of fuel
Lubricating Oil Engine Oil SE Class or Higher
Lubricating Oil Capacity 1.55 L
Starting System Cell Starter
Spark Plug NGK BPR6ES
Length × Width × Height 826 × 611 × 771 mm (826 × 766 × 856 mm)*
1
Dry Weight 143 kg (151 kg)*
2
Specifications are subject to change without notice.
Model E100
Type Brush, Self-exciting, 2-poles
Phase Single
AC Voltage 50 Hz 230 V
Max. Output 50 Hz 10.0 kw
Rated Output 50 Hz 8.5 kw
Rated Current 36.9 A
Voltage Regulator A.V. R Type
Power Factor 1.0
Safety Device N. F. B
Model Robin EH65D
Type Air-cooled, 4 cycle, OHV, Gasoline Engine
Displacement 653 cm
3
Max. Output 22.3 HP (16.4 kw)
Fuel Regular Automobile Gasoline
Fuel Tank Capacity 38.2 L
Rated Continuous Operation
50 Hz Approx. 8.9 h
per a tankful of fuel
Lubricating Oil Engine Oil SE Class or Higher
Lubricating Oil Capacity 1.55 L
Starting System Cell Starter
Spark Plug NGK BPR6ES
Length × Width × Height 826 × 611 × 771 mm (826 × 766 × 856 mm)*
1
Dry Weight 141 kg (149 kg)*
2
Specifications are subject to change without notice.
ALTERNATOR
ENGINE
DIMEN
-
SION
ALTERNATOR
ENGINE
DIMEN
-
SION
*
1
( ) shows dimensions with castors.
*
2
( ) shows dry weight with castors installed.
*
1
( ) shows dimensions with castors.
*
2
( ) shows dry weight with castors installed.
SPECIFICATIONS
