3.3 Magnetic Sensor Attachment
The usage of the EUP-B712 can be extended by applying the optional
accessory. The accessory is the Magnetic sensor with which the EUP-B712
enables RVS (Real-time Virtual Sonography). There are two types of
Magnetic sensors, EZU-RV2S and EZU-RV3S. The Magnetic sensor
(EZU-RV2S) and the Magnetic sensor (EZU-RV3S) are shown in Fig. 13 and
Fig. 14.
Projected part
S
ensor (Black)
Fig. 13 Magnetic Sensor (EZU
-
R
V2S)
Direction mark
S
ensor
(
White)
Fig. 14 Magnetic Sensor (EZU
-
R
V3S)
