Hitachi HDR081 Service Manual

SERVICE MANUAL
SCART CONNECTION
20 18 16 14 12 10 8 6 4 2
21 19 17 15 13 11 9 7 5 3 1
TV Scart Socket
TV Scart Sock PL1et – 01
Pin Description Pin Description
1
Audio Right Output nnection
12
No Co
2
No Connection
13
GND
3
Audio Left Output
14
GND
4
GND
15
RED Output
5
GND
16
Fast Blanking Output
6
No Connection
17
GND
7
BLUE Output
18
GND
8
Function Switching Output
19
CVBS Output
9
GND
20
No Connection
No Connection
21
GND
10
11
GREEN Outp
ut
VCR Scart Socket
VCR Scart Sock PL1et - 00
Pin Description Pin Description
1
Audio
Right Output
nnection
12 No Co
2 Audio Right Input 13 GND
3 Audio Left Output 14 GND
4 GND 15 No Connection
5 GND 16 No Connection
6 Audio Left Input 17 GND
7 No Connection 18 GND
8 Function Switching Input t 19 CVBS Outpu
9 GND 20 CVBS Input
10 No Connection 21 GND
11 No Connection
Page 24
