CONNECTION DIAGRAMS
ONLY
THIS SCART LEAD
IS SUPPLIED
"Optional RF lead if you
still wish to watch analogue
channels on the TV”
TV SCARTVCR SCART
ANTENNA 1
OUT
ANTENNA 1
IN
RS 232
CVBS
LEFT
RIGHT
OPTICAL OUT
ANTENNA 2
OUT
ANTENNA 2
IN
AC IN
35020157
TV Aerial
LOOP THROUGH
AC3 DOLBY DIGITAL
AMPLIFIER
VCR
VCR SCART
VCR
VCR SCART
TV Aerial
DO NOT REMOVE
Aux
HI-FI
Aux
HI-FI
NOTE: This set top box supports Free To View only. There is no provision for a CAM or Pay To View
card.
