Hitachi HDR161 User Manual

11
CONNECTION DIAGRAMS
ONLY
THIS SCART LEAD
IS SUPPLIED
"Optional RF lead if you
still wish to watch analogue
channels on the TV”
TV SCARTVCR SCART
ANTENNA 1
OUT
ANTENNA 1
IN
RS 232
CVBS
LEFT
RIGHT
OPTICAL OUT
ANTENNA 2
OUT
ANTENNA 2
IN
AC IN
35020157
TV Aerial
LOOP THROUGH
AC3 DOLBY DIGITAL
AMPLIFIER
VCR
VCR SCART
VCR
VCR SCART
TV Aerial
DO NOT REMOVE
Aux
HI-FI
Aux
HI-FI
NOTE: This set top box supports Free To View only. There is no provision for a CAM or Pay To View
card.

Hitachi HDR161 Specifications

General

Brand	Hitachi
Model	HDR161
Category	DVR
Language	English
