REMOTE CONTROL
Operating Distance 10m Max.
Batteries 2x1.5V Micro (R-03/AAA)
TUNERS
2 xRF In
IEC-type, female (75Ohm)
2 x RF Out (loop through) IEC-type, male (75Ohm)
HARD DISK
Hard Disk capacity 160 GB
FRONT PANEL
Display VFD
Front Panel Control Keys
Standby ON/OFF, Record, Play/Pause, Menu,
OK, Menu Up/Down/Left/Right.
AUDIO R / L
Connector 2 x RCA (R + L)
Output 2 Vrms, 0 dBfs / Z = 10 kohm
DIGITAL AUDIO
Output Optical SPDIF
A / V & DATA IN / OUT
Scart TV scart, VCR scart
RGB Video Output TV scart
RGB Video Intput VCR scart
CVBS Video Output TV scart, VCR scart
CVBS Video Input VCR scart
Analog Audio Output TV scart, RCA jack , VCR scart
Analog Audio Input VCR scart
Digital Audio Output Optical output
Data Interface RS232 (max 115200 bps), 9Pin
* Any changes in the Instruction Manual format is reserved.
