Hitachi KC95E - Side View; Rear View

GB
10
Side View
1
6
5
4
2
3
1. VOLUME Control
2. MW/FM Selector
3. TUNING Control
4. Projector Lens
5. Projector
6. ROTATE IMAGE Switch
AC ~6.5V 400mA
Rear View
2
3
4
1
5
6
7
1. Speaker
2. NIGHT LIGHT ON/OFF
Selector
3. FM Aerial
4. Backup Clock Battery
Compartment
5. ALARM1 Selector
(RADIO/BUZZ/OFF)
6. ALARM2 Selector
(RADIO/BUZZ/OFF)
7. DIMMER Selector
(HI/LOW)
8. AC Socket
