Hitachi L32A02A - Troubleshooting: Sound No Picture

Hitachi L32A02A
45 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
OK
NG
OK
NG
NG
Change main
board assembly
OK
NG
TV has
but no
sound
Check CON16 Pin15
Pin16&Pin17&Pin18=12V
Change power
board assembly
Check U23 Pin2 3.3V
Check U1,U2,U10,U29
voltage stable or not
Change main
board assembly
Change power
board assembly
OK
Check CON3 Pin7& Pin8
&Pin11&Pin12=24V
END
Troubleshooting
-33-
