7-2. Name Plate
Each tool is provided with a Name Plate which lists the following basic safety precautions in the use of the tool.
8. REFERENCE MATTERS
8-1. Collet Chuck
The collet chuck portion consists of a collet chuck and a collet nut. The collet chuck and the nut are assembled as
a single unit to maintain desired dimensional accuracy. Therefore, when replacing the collet chuck portion, be
sure to replace it entirely.
(1) For the U.S.A. and Canada
(2) For Australia, New Zealand and South Africa
9. PRECAUTIONS IN DISASSEMBLY AND REASSEMBLY
The [Bold] numbers in the descriptions below correspond to the item numbers in the Parts Lists and exploded
assembly diagram for the Model M 8V2. The ([Bold]) numbers in the descriptions below correspond to the item
numbers in the Parts Lists and exploded assembly diagram for the Model M 8SA2. The disassembly and
reassembly procedures described are the same for the Models M 8V2 and M 8SA2.
CAUTION: Prior to commencing disassembly, inspection or other maintenance, ensure without fail that
the plug is disconnected from the power source.
