9-2. Reassembly
Reassembly can be accomplished by following the disassembly procedures in reverse.
Fig. 7
(1) Wiring procedure
During installation, be careful not to pinch the lead wires between the housing and the head cover.
Connector
Controller
Switch
(1-1) Model M 8V2
Fig. 8
(1-2) Model M 8SA2
Noise suppressor
Switch
