10
Item
No.
Part Name Q’TY
1 HEX. SOCKET HD. BOLT M5 × 25 2
2 TOP COVER 1
3 HEX. SOCKET HD. BOLT M5 × 20 4
4 EXHAUST COVER 1
5 WARNING LABEL (A) 1
6 GASKET (F) 1
7 GASKET (C) 1
8 EXHAUST VALVE 1
9 HEAD CAP ASS’Y 1
10 PISTON O-RING 1
11 PISTON 1
12 O-RING (I.D. 64.5) 3
13 CYLINDER O-RING (D) 1
14 CYLINDER PLATE 1
15 CYLINDER 1
16 CYLINDER RING 1
17 CYLINDER SPRING 1
18 CYLINDER O-RING (A) 1
19 CYLINDER GUIDE 1
20 CYLINDER O-RING (B) 1
21 NAME PLATE 1
22 BODY ASS’Y 1
23 CYLINDER O-RING (C) 1
24 PISTON BUMPER 1
25 BUMPER SHEET 1
26 GASKET (A) 1
27 NOSE 1
28 NYLOCK HEX. SOCKET HD. BOLT M5 × 16 4
29 HEX. SOCKET HD. BOLT M5 × 10 2
30 GUIDE PLATE 1
31 ROLL PIN D4 × 16 1
32 BLADE GUIDE 1
33 LOCK LEVER 1
34 ROLL PIN D3 × 30 1
35 HEX. SOCKET HD. BOLT M5 × 18 2
36 WASHER 2
37 GUARD 1
38 SLEEVE 1
39 GRIP RUBBER 1
40 NYLON NUT M5 4
41 GASKET (D) 1
42 CAP 1
43 HEX. SOCKET HD. BOLT M5 × 16 3
44 AIR PLUG NPT 1/4 1
45 HITACHI PLATE 1
46 VALVE GUARD 1
47 ROLL PIN D3 × 45 1
48
MACHINE SCREW (W/SP. WASHER) M5 × 16
1
49 HOLDER SPRING 1
50 SAFETY BOLT 1
51 NUT M5 1
52 PUSHING LEVER 1
53 ADJUSTER 1
54 RATCHET SPRING 2
55 PUSHING LEVER (A) 1
56 PLUNGER SPRING 1
57 PLUNGER (A) 1
58 PLUNGER O-RING 1
59 O-RING (S-12) 3
60 VALVE BUSHING 1
61 PLUNGER (B) 1
62 VALVE PACKING 1
63 URETHANE BALL (C) D7.14 1
64 VALVE PLATE 1
65 TRIGGER VALVE BUSHING 1
66 PLUNGER O-RING 1
67 TRIGGER PLUNGER 1
Item
No.
Part Name Q’TY
68 TRIGGER 1
69 ROLL PIN D3 × 30 (10 PCS.) 1
70 HANDLE ARM 1
71 WARNING LABEL 1
72 MAGAZINE COVER 1
73 RIBBON SPRING 1
74 COVER SPRING 1
75 ROLL PIN D3 × 81
76 MAGAZINE PIECE 1
77 STAPLE FEEDER 1
78 HINGE PIN 1
79 MAGAZINE ASS’Y 1
80 MACHINE SCREW (W/WASHERS) M5 × 14 2
81 LABEL 1
501 SAFETY GLASSES 1
02Back_N50024A2_Eng 08/7/31, 22:4010
