Type of power Piston reciprocating
Air pressure (Gauge) 4.9 – 8.3 bar (70 – 120 psi.)
Applicable staples ref. Fig.
Amount of loadable staples 150 staples
Size 360 mm (L) × 250 mm (H) × 76 mm (W) (14-11/64” × 9-13/16” × 3”)
Weight 2.1 kg (4.7 lbs)
Hose (inside diam.) 6 mm (1/4”)
SPECIFICATIONS
NAME OF PARTS
Fig. 1
Piston
Piston O-Ring
Driver Blade
Nose
Guide Plate
Lock Lever
Blade Guide
Push Lever (A)
Firing Head
(outlet)
Staple Feeder
Magazine Assembly
Magazine Cover
Air Plug
Cap
Body
Trigger
Exhaust Cover
