POWER TOOLS
TECHNICAL DATA
AND
SERVICE MANUAL
STAPLER
N 5008AC
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. E003 Oct. 2001
N
MODEL
N 5008AC

Table of Contents

Other manuals for Hitachi N 5008AC

Preview: Instruction And Safety Manual
Instruction And Safety Manual44 pages
Preview: Handling Instructions
Handling Instructions42 pages

Questions and Answers

  • N
    Nichole LevyAug 9, 2025
    What to do if staples bend when using Hitachi N 5008AC?
    • A
      Alice RobinsonAug 9, 2025
      If staples are bending while being driven with your Hitachi Power Tool, it could be due to several reasons. It might be that the staples are not fully fed into the injection port. It might be that you are using unspecified staples. In these cases, refer to item 1. Another possibility is a worn driver blade, which should be replaced. Lastly, the material you're driving into might be too hard; the tool isn't designed for such hard materials.
  • W
    william25Oct 25, 2025
    Why won't staples drive in my Hitachi Power Tool?
    • R
      Robert ElliottOct 25, 2025
      If staples cannot be driven using your Hitachi Power Tool, several factors could be at play. First, ensure that you are using the specified genuine staples. If you're already using the correct staples, check for any abnormal staples (bent, abnormal collation, etc.) and replace them with normal ones. Also, inspect the staple feeder for burrs, deformation, or damage; correct or replace as necessary. Similarly, check the ribbon spring; a fatigued or damaged spring should be replaced. If the staple rail width is too wide or the magazine cover is deformed or damaged, replace these parts. Adhesive fragments or wood chips on the magazine, staple feeder, or staple rail can also cause issues; clean these components and apply oil to the staple feeder. Ensure that the air pressure is correctly adjust...

Summary

Specifications

Specifications

Staple Selection

Staple Driving Force

Describes the stapler's output energy and required energy for driving staples flush.

Precautions in Sales Promotion

Mechanism and Operation Principle

Mechanism

Operation Principle

Details how the stapler functions through various stages of operation.

Troubleshooting Guide

Troubleshooting and Correction

Provides solutions for common problems like staples not being driven.

Possible Causes and Corrections of Air Leakage

Identifies locations and causes of air leaks and their repair methods.

Disassembly and Reassembly

General Precautions in Disassembly and Reassembly

Disassembly and Reassembly of the Output Section

Disassembly and Reassembly of the Control Valve Section

Disassembly and Reassembly of the Driving Section and the Magazine Section

Inspection and Confirmation After Reassembly
