--- 4 ---
5-3. Nail Selection
The Model NR 83A2 utilizes round-head nails collated with plastic resin into bands of 32 to 35 pieces.
Applicable nail dimensions are shown below.
CAUTION: Ensure that nails are as specified in Fig. 1. Other nails will cause clogging of nails and
subsequent damage to the nailer.
7 mm
(0.286")
2.9 mm
(0.113")
50 mm (2")
Minimum
Plastic-collated strip nails full-head nails
Fig. 1 Dimensions of nail
Maximum
7.6 mm
(0.3")
83 mm (3-1/4")
21 deg.
