Hitachi PDA-100K Technical Data And Service Manual

*
ALTERNATIVE PARTS
--- 2 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
12 -- 03
PDA-100K
1 949-242 MACHINE SCREW M5X22 (10 PCS.) 4
2 949-454 SPRING WASHER M5 (10 PCS.) 4
3 301-944 PUSHING BUTTON 1
4 316-484 GEAR COVER ASS’Y 1 INCLUD. 3, 17
5 301-941 SPECIAL NUT M7 1
6 628-VVC BALL BEARING 628VVC2PS2-L 1
7 316-480 BEARING HOLDER 1
* 8 360-567C ARMATURE 110V 1
* 8 360-567E ARMATURE 220V-240V 1
9 319-898 FAN GUIDE 1
10 320-677 TAPPING SCREW D4X70 2
* 11 340-514C STATOR (A) 110V 1
* 11 340-514E STATOR (A) 220V-230V 1
* 11 340-514G STATOR (A) 220V-230V 1 FOR CHN, KOR
* 11 340-514F STATOR (A) 240V 1
12 313-775 DUST SEAL 1
13 626-VVM BALL BEARING 626VVC2PS2L 1
14 309-929 RUBBER BUSHING 1
15 316-487 RETAINING RING FOR D11 SHAFT 1
16 316-486 WAVE WASHER 1
17 301-943 LOCK PIN 1
18 997-263
SEAL LOCK SCREW (W/SP. WASHER) M4X10 2
19 316-490 BEARING COVER 1
20 620-1VV BALL BEARING 6201VVCMPS2L 1
21 301-946 FELT PACKING 1
22 316-489 PACKING GLAND 1
23 307-127
SEAL LOCK SCREW (W/SP. WASHER) M4X12 4
24 302-047 WOODRUFF KEY 1
25 316-485 SPINDLE 1
26 301-945 FRINGER 1
27 308-386
MACHINE SCREW (W/SP. WASHER) M5X16 (BLACK) 2
28 301-949 SET PLATE 1
29 301-948 WHEEL GUARD ASS’Y 1 INCLUD. 27, 28
* 30 320-497 WHEEL WASHER 1
* 30 320-496 WHEEL WASHER 1 FOR KOR
* 31 316-820 D. C. WHEELS 100MMX4T A36Q (25 PCS.) 1
* 31 939-640 D. C. WHEELS 100MMX4T A36Q (20 PCS.) 1 FOR KOR
* 32 321-795 WHEEL NUT (C) 1
* 32 938-062 WHEEL NUT (B) 1 FOR KOR
33 321-450 GEAR AND PINION SET 1
34 HITACHI LABEL 1
35 320-675 HOUSING ASS’Y 1 INCLUD. 14
36 NAME PLATE 1
37 322-533 TAIL COVER (A) 1
38 302-086
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 1
39 306-664 TAPPING SCREW (W/FLANGE) D4X40 1
40 936-551 BRUSH CAP 2
41 999-021 CARBON BRUSH (1 PAIR) 2
42 313-777 BRUSH HOLDER 2
* 43 314-854 EARTH TERMINAL 1 FOR TPE
* 44 980-063 TERMINAL 1 FOR NOISE SUPPRESSOR
