Durable bearing of the gear cover spindle
The bearing of the gear cover spindle was changed from the metal bearing to the needle bearing to increase
the service life and durability.
Low gear noise
The gear fastening method is changed from the conventional press-fitting method to the new method. The
gear is fastened to the spindle by a woodruff key keeping a proper clearance to reduce the variations in gear
noise level to the minimum level.
Depressed
center
wheel
5. SPECIFICATIONS
4,300 m/min (14,100 ft/min, 72 m/s)
Dimensions
Model
Item
O.D. 100 mm (4") x Thickness 6 mm (1/4")
x I.D. 16 mm (5/8")
Offset amount: 4 mm (5/32")
Max. peripheral speed
PDA-100K
AC single phase 50 or 60 Hz
Power source
Glassfiber reinforced polyamide resin (black)
Aluminum alloy die casting (metallic silver)
Aluminum alloy die casting
1.5 kg (3.3 lbs.) 1.4 kg (3.1 lbs.)
2.5 kg (5.5 lbs.) 2.4 kg (5.3 lbs.)
Corrugated cardboard box
Rotation speed (no-load)
Type of motor
Type of switch
Enclosure
Net: *
1
Gross:
Packaging
Standard accessories*
2
Depressed center wheel [Outer dia.100 mm (4") ] .................1
Wrench...................................................................................1
Voltage, current and power input
12,000/min
AC single-phase commutator motor
Snap switch
Housing
Tail cover
Gear cover
Packing gland
Voltage (V)
110
220
230
240
Current (A)
6.7
3.3
3.2
3.1
Power input (W)
705
*
1
: Net weight excludes cord, depressed center wheel, wheel nut, wheel washer and wheel guard.
*
2
: Standard accessories are subject to change without prior notice.
G 10SK3
Aluminum alloy die casting (metallic
silver) and glassfiber reinforced
polyamide resin (green)
Glassfiber reinforced polyamide
resin (green)
Weight
To Next Page
