Hitachi PDA-100K Technical Data And Service Manual

*
ALTERNATIVE PARTS
--- 2 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
12 -- 03
G 10SK3
1 320-523 TAPPING SCREW D5X25 (BLACK) 4
2 301-944 PUSHING BUTTON 1
3 316-484 GEAR COVER ASS’Y 1 INCLUD. 2, 16
4 301-941 SPECIAL NUT M7 1
5 628-VVC BALL BEARING 628VVC2PS2-L 1
6 316-480 BEARING HOLDER 1
* 7 360-567C ARMATURE 110V 1
* 7 360-567E ARMATURE 220V-240V 1
8 319-898 FAN GUIDE 1
9 319-358 TAPPING SCREW (W/FLANGE) D4X70 2
* 10 340-514C STATOR (A) 110V 1
* 10 340-514E STATOR (A) 220V-230V 1
* 10 340-514G STATOR (A) 220V-230V 1 FOR KOR
11 313-775 DUST SEAL 1
12 626-VVM BALL BEARING 626VVC2PS2L 1
13 319-093 RUBBER BUSHING 1
14 316-487 RETAINING RING FOR D11 SHAFT 1
15 316-486 WAVE WASHER 1
16 301-943 LOCK PIN 1
17 997-263
SEAL LOCK SCREW (W/SP. WASHER) M4X10 2
18 316-490 BEARING COVER 1
19 620-1VV BALL BEARING 6201VVCMPS2L 1
20 301-946 FELT PACKING 1
21 316-489 PACKING GLAND 1
22 307-127
SEAL LOCK SCREW (W/SP. WASHER) M4X12 4
23 302-047 WOODRUFF KEY 1
24 316-485 SPINDLE 1
25 301-945 FRINGER 1
26 308-386
MACHINE SCREW (W/SP. WASHER) M5X16 (BLACK) 2
27 301-949 SET PLATE 1
28 301-948 WHEEL GUARD ASS’Y 1 INCLUD. 26, 27
* 29 320-497 WHEEL WASHER 1
* 29 320-496 WHEEL WASHER 1 FOR KOR
* 30 316-820 D. C. WHEELS 100MMX4T A36Q (25 PCS.) 1
* 30 939-640 D. C. WHEELS 100MMX4T A36Q (20 PCS.) 1 FOR KOR
* 31 321-795 WHEEL NUT (C) 1
* 31 938-062 WHEEL NUT (B) 1 FOR KOR
32 321-450 GEAR AND PINION SET 1
33 HITACHI LABEL 1
34 320-666 HOUSING ASS’Y 1 INCLUD. 13
35 NAME PLATE 1
36 320-668 TAIL COVER (A) 1
37 302-086
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 1
38 306-664 TAPPING SCREW (W/FLANGE) D4X40 1
39 936-551 BRUSH CAP 2
40 999-021 CARBON BRUSH (1 PAIR) 2
41 313-777 BRUSH HOLDER 2
* 42 314-854 EARTH TERMINAL 1 FOR TPE
* 43 980-063 TERMINAL 1 FOR NOISE SUPPRESSOR
* 44 938-307 PILLAR TERMINAL 1 FOR SIN, MAL
* 45 959-140 CONNECTOR 50091 (10 PCS.) 1 EXCEPT FOR SIN, MAL
