TECHNICAL SPECIFICATIONS
Power supply AC adapter : AC 230V ~ 50Hz
DC source : DC 12V / 2000mA ( center positive )
Power Consumption 25W
Screen Display 7” / 16:9 TFT panel
Discs Played DVD-Video, CD-DA, CD-R/RW, MP3, JPEG, VCD 2.0
Video Formats PAL / NTSC
Audio out Analog audio out : 1V @ 10K ohm load
Frequency Response 20Hz ~ 20KHz +/- 3dB
Video out Compositive video 1.0Vp-p 75 ohm
Input Analog audio / Compositive video
Battery Rechargable Li-ion battery : 7.4V / 4000mA
Recharging time : approx. 3 hours
Playback time : approx. 150 mins ( TFT = on )
approx. 240 mins ( TFT = off )
Dimension Main unit : ( 202 x 153 x 27.3 ) mm
Battery pack : ( 197 x 82 x 27 ) mm
Weight ( without battery ) Approx. 730gm
Design and specifications are subject to change without notice
