CONNECTIONS
3. Connecting Using S-Video Cable ( optional extra )
4. Connection for in car use
Use the Car Power Adaptor for power when using the DVD player in a car.
1.Plug the adaptor into the car cigarette lighter.
2.Plug the pin into the DC jack on the unit.
5
To Car Power Adaptor
To DC IN Jack
A/V
OPTICAL OUT
VIDEOS-VIDEO
IN
DC IN 12V
AUDIO
OUT
VOLUME A/V
OPTICAL OUT
VIDEOS-VIDEO
IN
DC IN 12V
AUDIO
OUT
TV
AudioVideo
LR
S-Video
()Optional Extra
S-Video Cable
manual.p65 3/25/04, 10:11 AM7
To Next Page
