Hitachi PSC-A1T User Manual

3
/
6
ELECTRICAL WIRING
b) Using Timer with PC-2H2
3. In case of using Timer with PSC-A64S or PSC-5S (Central Station)
DSW1- 4 pin OFF
DSW2- 2 pin OFF
PSC-A1T
PSC-A64S
or
PSC-5S
A
ccessor
y
Cable (1m)
Connector
To other central
Stations
Twist Pair Cable
1P-0.75mm²
(Max. 1000m)
A
vailable for H-LINK
connection (to be
connected to the
terminal boards 1
and 2 of Indoor unit
or Outdoor unit
 Up to 8 units of central Station (PSC-A64S) and Timer
(PSC-A1T) can be connected to the H-LINK system.
 One Timer control one Central Station and plural central
Stations can not be controlled by one Timer
Power Supply:
A
C220V or 240V
CN1
TB2
PSC-A1T
PC-2H2
Indoor Unit
Transmission Wire
between Outdoor Unit and
indoor Unit (H-LINK)
A
ccessor
y
Cable
(
1m
)
TIMER
REMOCON
(white)
(yellow)
Connector
CN12 or CN13

Hitachi PSC-A1T Specifications

General

Brand	Hitachi
Model	PSC-A1T
Category	Controller
Language	English
