APPLICATIONS
For charging the HITACHI batteries type BCL10 series.
CHARGING METHOD
NOTE: Before plugging into the receptacle, make sure the following points.
䡬 The power source voltage is stated on the nameplate.
䡬 The cord is not damaged.
WARNING: Do not charge at voltage higher than indicated on the nameplate.
If charged at voltage higher than indicated on the nameplate, the
charger will burn up.
1. Insert the plug of battery charger into the receptacle.
When the plug of battery charger has been inserted into the receptacle, pilot lamp will
blink in red. (At 1-second intervals)
WARNING:
Do not use the electrical cord if damaged. Have it repaired immediately.
SPECIFICATIONS
Input power source Single phase: AC120V 60Hz
BCL1015S .......................... Approx. 25 minutes
Charging time BCL1015 ............................ Approx. 30 minutes
BCL1030 ............................ Approx. 60 minutes
Charger
Charging voltage .............................. DC 10.8 V
Charging current .............................. DC 3.0 A
Weight 0.8 lbs (0.35 kg)
