11.1 MAIN SAFETY DEVICE
Compressor Protection
High Pressure Switch:
This switch cuts out the operation of the compressor when the discharge pressure exceeds the setting.
Fan motor protection
When the thermistor temperature is reached to the setting, motor output is decreased.
The other way, when the temperature becomes lower, limitation is cancelled.
Model RAS-(4-6)HV(R/N)(C/P)2E RAS-(4-6)H(R/N)(C/P)2E
For compressor
Pressure switches - Automatic Reset, Non-Adjustable (each one for each compressor)
-0.05
High Cut-Out MPa 4.15
-0.15
Cut-In MPa 3.20±0.15
Low Cut-Out MPa 0.20
for control Cut-In MPa 0.30
Fuse -
1~ 230V 50Hz A 50 -
3N~ 400V 50Hz A - 2 x 20
CCP Timer - Non-Adjustable
Setting time min. 3
For condenser fan motor
- Automatic Reset, Non-Adjustable (each one for each motor)
Internal thermostat
For control circuit
A 5
Fuse on PCB
Commissioning
PMML0545 rev.2 - 04/2021
18
EN
