OPERATOR’S STATION
1-21
EMERGENCY EXIT (cab-equipped machines)
If the operator’s cab door can not be opened in an emer-
gency, escape in the following methods.
1. When required to escape from the cab when the door
is difficult or impossible to open in an emergency,
open the front window.
NOTE: Refer to the descriptions in OPEN-
ING/CLOSING CAB FRONT WINDOW for the
opening method of the front window.
WARNING: Be sure to wear safety glasses when
require to break the windowpane.
2. In case opening the front window is impossible, break
the front window glass with emergency evacuation
hammer (1) provided on the rear side in the cab to
escape through the broken window.
3. If the front window is not available for escaping, break
the rear window glass with emergency evacuation
hammer (1). Then, escape through the broken win-
dow.
NOTE: Emergency exit decal is affixed on the front and
left rear window.
M1M7-01-020
M1M7-01-037
M1M7-01-038
1
Fron
