TH-TUNE
Air-Air and Water-Air autonomous units
DESCRIPTION OF MODBUS PARAMETERS
To be able to change the MODBUS parameters from the THTUNE terminal, the communications must first be enabled with a PGD1 or a
MiniPGD terminal: Enable the supervisor in the factory level menu and enable Start / Stop of the unit through supervisor.
ADDRESS PARAMETER CONFIGURATION
Press the central button until ADDR appears.
Turn the central button to select the direction
(1-200).
Press the central button once to confirm.
BAUD (RATE) PARAMETER CONFIGURATION
Press the central button until BAUD appears.
Turn the central button to select the speed.
(0, 1, 2, 3, 4)
0 → 1200
1 → 2400
2 → 4800
3 → 9600
4 → 19200
Press the central button once to confirm.
