HT-100P Series
HITROL CO., LTD. 6
Precautions
for Removal
Precautions
for Transport
& Assembly
Precautions
for Connecting
to Ground
Safety &
Environment
■ Precautions for Use
- Make sure to connect the product and vessel using required tools for sure.
- Keep the lock key safe and make sure that it is locked.
- Do not apply high impact to the product.
■ Precautions for Wiring
- Wire should be corrected to terminals that correspond to the locations of contact
points (refer to the connection method).
- Wire and supply the power to the device after checking the specifications.
- Entering the incorrect power voltage may cause damage or failure of the machine.
- Pay attention to prevent electric shock.
■ Disposal of Product
- Make sure to separate the amplifier and main unit from housing before disposing the
products. Also, the amplifier shall be detached and discard the metal and non-metallic
materials. No part (ex. Mercury switch) has influence on the environment, so no special
attention is required.
■ Pay special attention to prevent any impact on the device during transportation or assembly.
■ Pay attention to prevent any damage to any packing when transporting or mounting
the machine to the vessel.
■ As shown below, connect the external grounding with the wire at 4 ㎟.
■ Check the level and presence of liquid in the tank before removing it.
■ Overheated product may cause burn, so wear gloves to remove it.
■ Remove it with the power disconnected.
■ Make sure that any O-ring or gasket is not damaged while opening or closing the cover.
외부접지 4㎟ (4mmSQ)
Make sure that it is not subject to any high impact when moving.
Make sure to insert a washer if the terminal lug is removed from the
ground terminal and subsequently reconnected. (loosening prevention)
