Hitron CODA56 - Hitron CODA56 Front Panel and LED Status

User Manual - CODA56 - Cable Modem 5
Front Panel (with Indicator LEDs)
Figure 2: CODA56 Cable Modem Front Panel
Upstream...Solid Green
or Blue when connected
to an upstream channel
Power...Green when powered on
Downstream...Solid Green
or Blue when connected
to a downstream channel
Online...Green when connected
to your Internet Service Provider
Chapter 1 Hardware Overview
