RECEIVING & INSTALLATION

NOTE: The HIX TT-180D is not compatible with the M&R Trilok pin

registration system.”

CAUTION: Before installing or operating the unit be sure to read

these instructions thoroughly. Disconnect all electric power before

performing maintenance on the unit. Never operate this equip-

ment with the power supply cover removed. If you ﬁ nd that this

should be necessary, contact a licensed electrician. Make sure

the circuit for this unit is well grounded.

WARNING: ULTRA VIOLET LIGHT CAN CAUSE SKIN AND EYE

IRRITATION OR BLINDNESS. TO PREVENT DAMAGE TO

YOUR EYES AND SKIN, AVOID DIRECT EXPOSURE TO THE

LAMP WHILE IT IS ON.

INSTALLATION

1. Carefully uncrate exposure unit from its shipping container.

2. Place exposure unit on a level surface close to the wall circuit to

be used.

WARNING: When using an extension cord, use 14 ga.-3 conductor.

Maximum length, 25’ (7.62m).

3. Check unit over for any transportation damage and make sure all

foreign objects, such as packing material, have been removed.

Clean top side of glass to remove any dust.

4. Remove vacuum pump from shipping container. Be sure to read

and follow all instructions included with the pump, especially ﬁ ll-

ing the pump with the supplied oil before use.

5. Plug pump into receptacle located on the back of the TT-180

exposure unit. Be sure the voltage switch on the pump is set to

the proper voltage for the unit (120v or 220v).

6. Connect vacuum hose on pump to ﬁ tting on the back right side

of the exposure unit lid.

SETUP

1. Plug in your unit to your power source and turn on power

switch.
