HJM RFC500 - Electric Supply Connection; Technical Characteristics

HJM_RFC_ENG_Rev.2_25-09-2018
Made in Spain
6/20
5. Hang the radiator in the supports fixed on the wall and, finally , completely screw
up the two security pieces of the supports.
ELECTRIC SUPPLY CONNECTION
This appliance is equipped with a supply cord H05V2V2-F 2x1.0mm² and bipolar
plug without earthing.
Connect the plug to the base outlet.
Check the condition of your electrical installation and connection cables.
This appliance doesn't require earthing connection, due it has double electrical
insulation.
Contact a licensed electrician for assistance.
TECHNICAL CHARACTERISTICS
Brand
Model
RFC
Type
RFC500
RFC1000
RFC1500
RFC2000
Rated Voltage
230 V~
230 V~
230 V~
230 V~
Rated Frequency
50 Hz
50 Hz
50 Hz
50 Hz
Rated Power Input
500 W
1000 W
1500 W
2000 W
Electrical
Protection Class
II
II
II
II
IP Protection
Degree
IP24
IP24
IP24
IP24
Dimensions
(LxHxD) (mm)
380x585x105
510x585x105
640x585x105
770x585x105
Weight (kg)
5,7
8,7
11,50
14,8
