ACTOR ADX 115 Sub A
Connections: 1x XLR Subwoofer Input
1x XLR Subwoofer Through
1x Speakon
®
Parallel Out
Subwoofer Input: XLR female (pin 1= Ground; 2= +, 3= -)
Input: Electronically balanced & floating
Input impedance: 20 k ohms
Sensitivity: +10 dBu (turned all the way up)
Max. input level: +22 dBu
Frequency response +/- 3dB: 1) 48 Hz – 130 Hz
Axial sensitivity 1W@1m: 2) 104 dB
Maximum SPL @1m: 2) 126 dB @ 10% THD
Subwoofer amplifier: 1x 1000 W / Class D
Active protective circuits: DDO™ Controller, Multiband Limiter, Subsonic Filter
Woofer: 15"
Pole mount: M20 thread base plate
Castors Four 100 mm castors on the rear panel
Dimensions (WxHxD): 48 cm x 65 cm x 66 cm incl. castors
18 7/8" x 25 5/8" x 26"
Weight: 36.6 kg/ 80.0 lbs.
General electrical data:
Protection class 1 (protectively earthed)
Max. current consumption: 4.4 A (220 - 240 V)
8 A (100 - 120 V)
Max. power consumption: 1000 W
Mains voltage range: +/- 10%
Ambient temperature range during operation: -10° C to +35° C
Internal fuses: T8A
ACTOR ADX 115 Sub B
Connections: 1x Speakon
®
Input
Nominal power handling: 500 W RMS/ 8 ohms
Frequency response +/- 3dB: 1) 48 Hz – 130 Hz
Axial sensitivity t 1W@1m: *) 104 dB
Maximum SPL @1m: *) 126 dB @ 10% THD
Woofer: 15"
Pole mount: -
Castors Four 100 mm castors on the rear panel
Dimensions (WxHxD): 48 cm x 65 cm x 66 cm incl. castors
18 7/8" x 25 5/8" x 26"
Weight: 33.7 kg/ 74.3 lbs.
This is to certify that
HK AUDIO
®
ACTOR DX
complies with the provisions of the Directive of
the Council of the European Communities on
the approximation of the laws of the Member
States relating to electromagnetic compatibility
according to EMC Directive 89/336/EEC including
amendment 93/68/EEC and the low voltage Direc-
tive 73/23/EEC including amendment 93/68/EEC.
This declaration of conformity of the European
Communities is the result of an examination
carried out by the Quality Assurance Department
of STAMER GmbH in accordance with European
Standards EN 50081-1, EN 50082-1and EN 60065
for low voltage.
Magdeburger Str. 8
66606 St.Wendel
Lothar Stamer Dipl.Ing.
Managing Director
St.Wendel, 04/15/05
