8 Technical Specifications
ACTOR ADX 112 A
Connections: 1x XLR Line In
1x XLR Line Through
1x XLR Subwoofer Output
Line In: XLR female (pin 1= Ground; 2= +, 3= -)
Input: Electronically balanced & floating
Input impedance: 20 k ohms
Sensitivity: Switchable from –10 dB to 0 dB (= +4 dBu)
Max. input level: +22 dBu
Frequency response +/- 3dB:1) 80 Hz – 19 kHz full-range mode
130 Hz – 19 kHz Stop-only mode
Axial sensitivity 1W@1m:2) 106 dB
Maximum SPL @1m: 2) 129 dB @ 10% THD
Mid/high-range amplifier: 1x 600 W/ Class D
Active protective circuits: DDO™ Controller Multiband Limiter, Subsonic Filter
Midrange speaker: 12"
Tweeter/ driver: 1.4"
Directivity: 60° x 40° CD horn
Crossover frequency: 950 Hz, 12 dB/octave
Pole mount: HK AUDIO DuoTilt™, 36 mm, 7.5°, 15°
Rigging points: 4 M10 threaded bushings for attaching an optional rigging-bra-
cket
Accessories: ACTOR DX Tilt-Unit, 7.5°, 15°
Dimensions (WxDxH): 39 cm x 65 cm x 42 cm
15 1/4" x 25 5/8" x 16 1/2"
Weight: 32 kg/ 70.6 lbs.
General electrical data:
Protection class 1 (protectively earthed)
Max. current consumption: 13 A (220 - 240 V)
8 A (100 - 120 V)
Max. power consumption: 1000 W
Mains voltage range: +/- 10%
Ambient temperature range during operation: -10° C to +35° C
Internal fuses: T8A
1) Via active crossover
2) All measurements taken under half-space conditions
