Cadis™ Manual 1.0
Technical Data FirNet™ Controller
Connector Analog Input 3-pol. XLR female
Pin assignments 1 = ground, 2 = Signal(+), 3 = Signal(-)
Input impedance 9 k-ohm
Maximum input level Variable; 6, 12, 18, and 24 dBu
Dynamic range, input >128 dB (A)
Digital input 3-pol. XLR female
Pin assignments 1 = ground, 2 = Signal, 3 = Signal
Input impedance 110 ohms
Protocol AES 3 (AES/EBU)
Clock rate 48 or 96 kHz, and 96 kHz internal
Synchronization To an external source (slave mode)
Digital output 3-pol. XLR male
Pin assignments 1 = ground, 2 = Signal, 3 = Signal
Output impedance 110 ohms
Protocol AES 3 (AES/EBU)
Signal processing Refresh signal form and level (Bypass at power failure)
Analog outputs 3-pol. XLR male
Pin assignments 1 = ground, 2 = Signal(+), 3 = Signal(-)
Output impedance 35 ohms
Maximum output level Variable; 6, 12, 18, and 24 dBu
Dynamic range, output >125 dB(A)
Mains voltage connector Three-pole non-heating equipment connector
Mains voltage / frequency 100 to 240 V / 50 - 60 Hz
Power consumption 40 VA
Max. curr. cons. at 100 V mains voltage 400 mA
Max. curr. cons. at 230 V mains voltage 175 mA
Ethernet X port RJ-45, RJ-45, cross-connected
Ethernet II port RJ-45, RJ-45, direct-connected
Audio data (Linear Through mode)
Frequency response (-1 dB) 5.5 Hz to 34 KHz
THD+N (20 Hz bis 20 kHz) AD>DA input level 21 dBu,
R=100 k, 96 kHz 0,0012%-0,0013%
AES>DA input level -3dB FS,
R=100k, 96 kHz 0,0010% - 0,0012%
Latency (incl. limiter): AD > DA 96 KHz 3,15 ms
AD > AES/EBU 96 KHz
AES/EBU > A 96 KHz
+ FIR filter 5.8 ms (Cohedra / Coh. Compact)
Internal sampling rate 96 kHz
Internal data format 32 bit floating point
AD converter resolution 28 Bit
DA converter resolution 24 Bit
Temperature range -10° C to +70°C
Weight 3 kg • 6.,6 lbs.
Measurements (D x H x W) 48 x 4.4 x 23.2 cm
18-7/8 x 17-5/16 x 9-1/8"
